MLTG-CN is a Terragraph certified client node (CN). MLTG-CN supports IEEE802.11ay standard to deliver high-speed Internet in a noise-free and unlicensed 60GHz spectrum. When connected with Terragraph certified distribution node (DN), MLTG-CN can function as Customer Premise Equipment (CPE) to provide last mile wireless gigabit connectivity to the client site, such as warehouse, company building, or residential area.
MLTG-CN can also be paired to deliver Point-to-Point (PtP) wireless gigabit throughput for backhaul or last mile access without the costly installation of cabled fiber.
Standards:
• 802.11ay
60GHz Radio:
• Phased array antenna with 64 antenna elements
• 90 degrees azimuth scan range: -45º to 45º
• 50 degrees elevation scan range: -25º to 25º
RF Output Power:
• Up to 38 dBm
Frequency Band:
• 57-66GHz
Modulation:
• BPSK
• QPSK
• 16QAM
• Type: Built-in phased array antenna
• Gain: 22 dBi
• 1 x Gigabit Ethernet Port (PoE In)
• 1 x Gigabit Ethernet Port
• 1 x 60GHz Radio
Power:
• 48~55V passive Gigabit PoE
Dimensions (L x W x H):
• 17.73 x 11.16 x 4.3 cm
Weight:
• 518 g
Environmental Conditions:
• IP66 Rating
• Operating Temperature: -20ºC (-4ºF) to 55ºC (131ºF)
• Storage Temperature: -20ºC (-4ºF) to 70ºC (158ºF)
• Operating Humidity: 5% to 95% non-condensing
• Wind Resistance: 208 km/h
Power Consumption:
• 24W max.
Mounting:
• Wall/Pole mount (Mounting kit included)
When connected to MLTG-360:
• Up to 100m (0.06 mi) for MCS12
• Up to 150m (0.09 mi) for MCS9
When connected to MLTG-CN:
• Up to 80m (0.05 mi) for MCS9
Throughput:
• 2 Gbps aggregated
• FCC
• IC
• CE
• VCCI
• TELEC
• RCM
• Support channel 1 to channel 4 (57-66GHz)
• Up to 2 Gbps bi-directional aggregate throughput
• Beamforming technology with phased array antenna for easy alignment
• Support TDMA-MAC for dynamic bandwidth allocation
• Support Over-the-Air (OTA) Security with AES128 encryption
• Support QoS with 4 service classes
• IPv6 tunneling
• Support Layer 2 Forwarding
– Support VLAN transparent transmission
– Support management VLAN
