- 8 Port
- 10G SFP+
- 8 x 10G
- 2 x 10G SFP+ Uplink
- 2 x RJ45 10G Uplink
- 1 x Console Port
- 1 x USB Port
- 240 Gbps Switching Capacity
- Support ecCLOUD
SUPPORT OPENLAN SWITCHING
The Edgecore ECS5500-12T/12P switch is a 10G Ethernet access switch with 8 x 10GBASE-T ports and 2 x 10G SFP+/2 x 10GBASE-T as uplink ports. The switch is ideal for SMB networks as a core switch. This switch is also positioned as cloud-edge access switch to connect IOTs and other devices in Enterprises and SMB deployments. It is also an ideal 10G access switch for SMB, enterprise, and campus networks, especially with its multi-Gig support for different 100M/1G/2.5G/5G/10G speed LAN devices. The ECS5500-12P is a PoE switch that can provide up to 60 watts (480 W budget) to power devices such as wireless access points (especially Wi-Fi 7), VoIP phones, surveillance cameras, IoT devices, and PoE-powered computers over Cat. 6a UTP cable, eliminating the need for individual power sources.
The ECS5500-12T/12P is packed with features that bring high availability, comprehensive security, robust multicast control, and advance QoS to the network edge, while maintaining simple management. The switch also supports the most advance IPv6 management, IPv6 security, and IPv6 multicast control in accordance with the growth of IPv6 deployment.
