- Indoor
- Concurrent Dual-Band 2.4GHz & 5GHz
- 2×2:2 UL MU-MIMO
- Support BLE/Zigbee/Thread
- 1 x GbE PoE WAN
- 1 x GbE LAN
- IP55
- External RP-SMA antennas
- Support ecCLOUD
SUPPORT OPENWIFI VERSION
EAP112 stands out as an enterprise-grade IoT Gateway, incorporating Wi-Fi6, HaLow, BLE, Zigbee, Thread, and LTE technologies to drive advanced AI solutions. EAP112 supports Wi-Fi 6 2×2 uplink and downlink MU-MIMO, delivering an impressive up to 3Gbps data rate within its IP65-rated enclosure. With Bluetooth Low Energy (BLE) radio, ZigBee, Thread, and HaLow capabilities, EAP112 facilitates the implementation of value-added applications like iBeacon and Matter, fostering seamless communication among diverse IoT devices. The inclusion of Wi-Fi HaLow addresses the need for long-range, low-rate data transmission, while the additional LTE interface serves as an alternative uplink connection to the internet. EAP112 offers the flexibility to operate in standalone mode or under the management of Edgecore ecCLOUD or the ecCLOUD-VPC controller.
Standards:
• 802.11ax (Wi-Fi 6)
• Concurrent dual-band 2.4 GHz & 5 GHz
Radio Chains:
• 2.4GHz: 2 x 2 ; 5GHz: 2 x 2
Spatial Streams:
• 2; Uplink and downlink MU-MIMO support
Aggregate Conducted Transmit Power:
• 2.4 GHz: Up to 25 dBm
• 5 GHz: Up to 25 dBm
Channelization:
• 2.4 GHz: 20 / 40 MHz
• 5 GHz: 20 / 40 / 80 / 160 MHz
Frequency Range:
• 2.401 – 2.483 GHz
• 5.170 – 5.835 GHz
Operating Channels:
• 2.4 GHz: 1-11 (US), 1-13 (Europe, Japan)
• 5 GHz : 36-165 (US), 36-140 (Europe), 36-144 (Japan)
ESSIDs:
• Up to 16 per radio (32 total)
